Fiberglass braided hose with AL film bonding on both sides

View full details
Raw materials are not available for standalone purchase; instead, they are intended to be integrated into a tailor-made, custom-engineered solution.

ZT-Heat-Pipe-Flex is a corrugated protective tube made of fiberglass braiding with aluminum foil bonding on both sides. The material combines dimensionally stable flexibility with very good temperature resistance and is suitable as thermal and mechanical protection in demanding environments.

Typical material properties

  • Material: Fiberglass braided hose with AL film bonding on both sides
  • Design: corrugated protective tube, dimensionally stable and flexible
  • Inner diameter: 9 mm to 40 mm
  • Wall thickness (diameter-dependent): approx. 2 mm ± 0.5
  • Temperature resistance: -40 °C to +250 °C
  • Fire behavior: non-flammable
  • Chemical behavior: good resistance to hydrocarbons, gasoline, oils, solvents and chemical agents.

Typical areas of application

  • Thermal protection of pipes and assemblies
  • Mechanical protection in temperature-stressed areas
  • Applications involving contact with oils, fuels or solvents
  • Industrial and plant environments with increased temperature requirements

Specifications

  • REACH:Compliant
  • Flammability:Self-extinguishing
  • Thickness:0.017 inch
  • Thickness deviation:+/- 15%
  • Maximum operating temperature:350°F (177°C)
  • Minimum operating temperature:-58°F (-50°C)
  • RoHS:RoHS-11
  • Durability:60 months
  • Tear resistance:>350 daN/50 mm (chain) | >250 daN/50 mm (filling)
  • Flexibility:Better

Specifications are subject to change without notice. All statements and technical information contained herein are based on tests we believe to be reliable, but accuracy or completeness cannot be guaranteed under all circumstances. Before using Zipper Technik products, the user must determine suitability for the intended use and assumes full responsibility for any improper selection.
